For Internal Use: FI.WR.INS.135_WBIN00031_Infinity_DrawerBox_Rev1 Page 2
DRAWER BOX
ADJUSTMENT, REMOVAL
INFINITY
Step 1.
Open the drawer that is required to be removed. Pull out the drawer until the runners are at full extension.
Press the locking mechanism to release the drawer from the runner and lift the drawer away from the
runners.
Step 2.
Fully extend the drawer runners out of the unit. Place the drawer onto the runners, making sure that the
groove of the drawer sides and the runner mechanism are aligned.
Once the drawer is placed onto the runners, push the drawer back into the unit until a click is heard. Once the
click is heard the drawer is properly located and secured to the runner.
