Wren INFRAMED KITCHEN - Page 28

WALL UNIT
Inframed kitchen Wall Unit Guide
For Internal Use: WKIN00289_Inframed_Kitchen_Guide_Rev3
Page 28
Step 11.
Using 2 x 40mm countersunk screws per unit, attach the top and bottom front rails to the top and bottom
xed shelf on the unit.
Make sure that the front of the rails sit 0.5mm back from the front of the side rails and is evenly spaced from
the front of the unit along the entire length. Make sure that the screw heads are ush with the rails.
