Wren WALL Series - Assembly Overview and Safety; Initial Safety Checks and Components

WALL/SHALLOW
BASE UNIT
150 - 600
WALL/SHALLOW BASE
Assembly Guide
For Internal Use: FI.WR.INS.034_WKIN00124_MULTI_150-600_WALL_ShallowBASE_Rev6.indd
Page 1
BEFORE YOU START
INSTALLATION
SHOULD BE
PERFORMED BY A
COMPETENT
PERSON ONLY.
THIS PRODUCT COULD
BE DANGEROUS
IF INCORRECTLY
INSTALLED
Panel A
x1 Back Panel
Hanging Bracket
x2 Inc Screws
(F) x8
Wooden Dowel
REQUIRED TOOLS
NOT to be used
with CAM DOWEL
& CAM LOCK
(G) x8
Cam Dowel
(Expanding)
(H) x8
Cam Lock
(K) x4
30mm
Screw
(L) x8
15mm
Screw
(S) x4
20mm
Screw
(M) x4
Cover Cap
(N) x1
Door
Buer
(Z) x8
Shelf Peg
Plastic
(T) x10
Back Panel
Support Clip
Hanging Bracket Plate
x2 (Screws NOT included)
Hinge Mounting Plate
x2 Inc Screws
Hinge
x2 Inc Screws
Corner Gusset
x2
Hanging Bracket
Cover Cap
x2
Panel B
x2 End Panel
Panel C
x2 Base Panel
Frontal
(packed separately)
x1
Shelf
x2
