WTC Technitron T2050 - Schedule #3 Programming

1``\YSQdY_^5hQ]`\U
$$ =_TYVYUT*( ! % ! DUSX^Ydb_^D" % GU \T3_^db_\
$VVLJQ6FKHGXOH
6. Assign Schedule #3 to re-clamp the parts with SV1 before the
second spot weld is made:
SCHEDULE=3
VALVE=1 ;Energize the gauging clamp SV1.
SQUEEZE DELAY=0 ;N/A
SQUEEZE=40 ;Give the clamp time to clamp and
align the parts.
UPSLOPE=0 ;N/A
WELD CYC=0 ;N/A
WELD CUR=20% ;N/A
COOL=0 ;N/A
IMPULSES=1 ;N/A
DOWNSLOPE CYC=0 ;N/A
SLOPE END CUR=20 ;N/A
QUENCH CYC=0 ;N/A
TEMPER CYC=0 ;N/A
TEMPER CUR=0 ;N/A
HOLD CYC=10 ;N/A
WELD COMPLETE=0 ;N/A
SUCCESSIVE SCH=0 ;N/A
CHAIN SCH=4 ;The part is now clamped, Go to
Schedule #4. Make the second
weld.
OFF CYC=0 ;N/A. The sequence jumped to
Schedule #4.
