WTC Technitron T2050 - Schedule #5 Programming

1``\YSQdY_^5hQ]`\U
$& =_TYVYUT*( ! % ! DUSX^Ydb_^D" % GU \T3_^db_\
$VVLJQ6FKHGXOH
Assign Schedule #5 to release and eject the part:
SCHEDULE=5
VALVE=0 ;Turn off the clamp and gun
before the clamp is energized.
SQUEEZE DELAY=0 ;N/A
SQUEEZE=40 ;Give the clamp and electrodes
time to open before ejection.
UPSLOPE=0 ;N/A
WELD CYC=0 ;N/A
WELD CUR=65% ;N/A
COOL=0 ;N/A
IMPULSES=1 ;N/A
DOWNSLOPE CYC=0 ;N/A
SLOPE END CUR=20 ;N/A
QUENCH CYC=0 ;N/A
TEMPER CYC=0 ;N/A
TEMPER CUR=0 ;N/A
HOLD CYC=10 ;N/A
WELD COMPLETE=30 ;Energize the ejector for a half-
second to eject the part. Use the
WCOMP output.
SUCCESSIVE SCH=0 ;N/A
CHAIN SCH=0 ;NA
OFF CYC=0 ;Off Single turns off all valves.
This completes the operation.
