%LQDU\9DOYH)XQFWLRQ7DEOH
FUNCTION Clamp Electrodes
Schedule & Valve # SV1 SV2 SV3 SV4
Sch. # 5 # 0 OFF OFF OFF OFF
Sch. # 1 & 3 # 1 ON OFF OFF OFF
Sch. # # 2 OFF ON OFF OFF
Sch. # 2 & 4 # 3 ON ON OFF OFF
Sch. # # 4 OFF OFF ON OFF
Sch. # # 5 ON OFF ON OFF
Sch. # # 6 OFF ON ON OFF
Sch. # # 7 ON ON ON OFF
Sch. # # 8 OFF OFF OFF ON
Sch. # # 9 ON OFF OFF ON
Sch. # # 10 OFF ON OFF ON
Sch. # # 11 ON ON OFF ON
Sch. # # 12 OFF OFF ON ON
Sch. # # 13 ON OFF ON ON
Sch. # # 14 OFF ON ON ON
Sch. # # 15 ON ON ON ON
