User Manual
15
y Press to confirm
Setting Tmin and Tmax
y Keep button
pressed to enter span selecting mode.
y Press
to select ManualSpan
y Press
to increase the Tmax value, press to decrease the value, press to switch to Tmin
adjustment mode.
y The same operation for Tmin adjustment.
y Press button “T” to save and exit.
Setting LCD brightness
y Press
to display the main menu.
y Press the “Parameter”
y Select “Brightness” by pressing “↑” and “↓”, and “OK” to confirm.
y Press
or to adjust the LCD brightness
y Press to confirm.
Picture Mode and Infra Fusion
The EASIR-9 could be displayed in full visual mode, full thermal mode and the confusion mode, they could be
switched.
y On real-time thermal mode, press the button of
to go into the picture mode, it would appear “Visual”, “Spot”
and “Fusion” on the button of the LCD screen
y Press the button of
to enter into the visual mode
y Press “Trigger” to switch to the real-time thermal status
y In the picture mode with the menu of “Visual”, “Spot” and “Fusion” displayed on the screen, press
to go into
the fusion mode.
y Press button
and button to adjust the fusion percentage, from full visual to full fusion.
y Press “Trigger” to switch to the full thermal image.
y In real-time status, press “Trigger” to froze thermal image, it would appear “Save”, “Voice” and “Visual” at the button
of the LCD screen. Press
to switch between thermal image and visual image
