User Manual
3
• AC Adapter & cable
• USB extension cable
• USB driver
• Guide IrAnalyser
®
Software
• User manual
• Carry case & strap
Options
• 13mm wide angle lens
• 42mm and 70mm , two tele lens are available
• 8GB SD card
• Extended temperature range up to +1500℃
• Sun Shield
• Tripod mount
Technical Specification
Imaging Performance
THERMAL
Detector type:
Uncooled FPA microbolometer (384×288 pixels, 25μm)
Spectral Range: 8-14μm
Thermal Sensitivity:
≤80mk at 30℃
Field of View/ Focus:
21.7°X16.4°/ 25mm standard (40.53°X30.96°/13mm, 13.04°X 9.8°
/ 42mm, 7.85°X 5.89°/70mm optional)
Focus: Manually
Electronic Zoom: X2
VISUAL
Built-in Digital Video: CMOS Sensor, 1600×1200 pixels, 2
24
true colors
Image Presentation
External Display: 3.6" TFT LCD with high resolution
Video Output: PAL/ NTSC
Infra Fusion: Visual and IR blending
Man-Machine Communication
Buttons: Respond as per operators’ operation
Menu: Microsoft
®
Windows style
Measurement
