WUNDER SA.BI.SRL EN USER MANUAL
RA(WU150) REV. 02- 10/01/2017 16
Lower the rod up to
the point where the
leverrests head
touches the patient's
head.
The height can be
read at the point 'A'
Lower the rod up to the point
in which the blade rests head
touches the patient's head.
The height can be read at
point 'B'.
16.2. ASSEMBE ELECTRONIC HEIGHT METER (OPTIONAL)
STAGE 1: INSTALLATION ALKALINE BATTERY
a. Removing battery cover at the
rear of indicator
b. Installing code AAA batteries *
2
c. Reinstalling the battery cover
STAGE 2: CONNECTING CABLE DIGITAL TELESCOPIC HEIGHT METER
Plug power digital telescopic height
meter
