Cold location controller for conventional plants, up to 4 control circuits (evaporator)
CRC-XP_V2.92_PI_2019-03_EN 3
Subject to technical modifications
CRC-XP
Software revision and validity of documentation
Any software versions not listed are special solutions for individual projects and are not described in detail in this
document. This document automatically ceases to be valid if a new technical description is issued.
Manufacturer: Wurm GmbH & Co. KG Elektronische Systeme, Morsbachtalstraße 30, D-42857 Remscheid
You can find more information on our website at www.wurm.de
.
1.3 Circuit diagram
Fig. 2: Circuit diagram
1.4 Installing and connecting
The module is designed for top-hat rail installation. The housing is a standard size and is also suitable
for installation in fuse boxes or distribution switch boxes. Modules can be positioned side by side with-
out gaps.
DANGER TO LIFE FROM ELECTRIC SHOCK AND/OR FIRE!
• Switch off the power to the entire plant before installing. Otherwise, mains voltage and/or exter-
nal voltage may still be present, even if the control voltage is switched off. Always remove both
power plugs (L and N).
• Only qualified electricians are permitted to wire the device.
• Take note of the maximum loads on all connections.
.
