Operating Controls
1
Front display
2
Speaker
3
Receiving area
4
On/Off button
5
Sensitivity button
6
Volume up/down button
7
Battery compartment lid
8
Rear display
9
Thread for holder
10
Holder for Hand
Intended Use
The receiver detects the laser lines (horizontal
or vertical) of our laser-line models with
hand-receiver function.
Tool Specifications
Line-laser Receiver
Article number 0714 640 131
Sensitivities
2 stages ±1.5 mm/±3 mm
Volume control Off, loud
Automatic shut-off Takes place after
6.5 min without a laser
impulse
Filter Protects against sun-
light and electromag-
netic interference
Reception angle 160°
Notch mark 50 mm from above
Dimensions 169 x 77 x 27 mm
Weight 275 g
Protection class watertight to IP 55
Battery type 9 V – 6LR61/6AM6
(alkali/manganese)
Battery service life up to 3 months
Working safely with this
machine is possible only
when the operating and
safety information are
read completely and the
instructions contained
therein are strictly fol-
lowed. Do not remove the label on the
side of the housing.
Observe the operating
instructions of the line la-
ser.
Do not look into the laser
beam.
❏ Use only original Würth parts and
accessories.
2
GB
For Your Safety
