Tool Specifications
Inserting/Replacing the Battery
Alkali-manganese batteries are recommended for the
measuring tool.
To open the battery lid 14, press the latch 15 in the
direction of the arrow and fold up the battery lid.
Insert the supplied battery. Pay attention that the
polarity is correct, according to the representation on
the inside of the battery lid.
The battery indicator h always indicates the current
battery status:
• Battery fully charged
• Battery has 2/3 of its capacity or less
• Battery has 1/3 of its capacity or less
• Please change battery
❏ If the measuring tool is not used for a long
period of time, the battery must be
removed. The battery can corrode or discharge
itself over long periods.
Initial Operation
❏ Protect the measuring tool against mois-
ture and direct sun light.
❏ Do not subject the measuring tool to
extreme temperatures or variations in tem-
perature. In case of large variations in
temperature, allow the measuring tool to
adjust to the ambient temperature before
switching it on. In case of extreme temperatures
or variations in temperature, the accuracy of the
measuring tool and the display indication can be
impaired.
❏ Use or operation of transmitting systems,
such as WLAN, UMTS, radar, transmitter
masts or microwaves, in the close proximity
can influence the measuring function.
Switching On and Off
❏ Before switching the measuring tool on,
make sure that the sensor area 12 is not
moist. If required, dry the measuring tool using a
soft cloth.
❏ If the measuring tool was subject to an
extreme temperature change, allow it to
adjust to the ambient temperature before
switching on.
To switch on the measuring tool, press the On/Off
button 5.
To switch off the measuring tool, press the On/Off
button 5 again.
When no button on the measuring tool is pressed for
approx. 5 minutes and when no objects are detected,
the measuring tool automatically switches off to save
the battery.
Switching the Display Illumination
On/Off
The display illumination can be switched on/off with
display-illumination button 6.
Switching the Audio Signal On/Off
The audio signal can be switched on/off with the
audio signal button 7. When the audio signal is
switched off, indication a appears on the display.
Digital Detector MD 12
Art. No. 5709 300 800
Maximum scanning depth*
–Ferrous metals
– Non-ferrous metals (copper)
– Live conductors 110–230 V
(voltage applied)**
– Wood
120 mm
80 mm
50 mm
38 mm
Automatic switch-off after
approx.
5min
Operating temperature –10 °C...+50 °C
Storage temperature –20°C...+70°C
Battery 1 x 9 V 6LR61
Operating life time, approx. 5h
Weight according to
EPTA-Procedure 01/2003 260 g
*depending on operating mode, material and size of the
objects, as well as material and condition of the base material
**less scanning depth for wires/conductors that are not “live”
❏ In terms of accuracy, the measuring result can
be inferior in case of unfavourable surface
quality of the base material.
