Würth MINI User Manual

9
Non-stationary workplace lamp
Item no. 0981 180 020
Item no. 0981 180 021
Item no. 0981 180 301
Item no. 0981 180 501
Lamp luminous ux
2,800lm
2,800lm
2,800lm
4,000lm
Luminous ux of illumi- nant
3,400lm
3,400lm
3,400lm
5,300lm
Colour temperature
5,000K
5,000K
5,000K
5,000K
Operating voltage
220 - 240V, 50/60Hz
220 - 240V, 50/60Hz
220 - 240V, 50/60Hz
220 - 240V, 50/60Hz
Capacity rating
33W
33W
33W
40W
Degree of protection
IP54
IP54
IP44
IP54
Protection class
II
I
I
I
Impact protection rating
IK08
IK08
IK08
IK08
Version
-
Switch, two sockets Ger-
man/Austrian standard (max. 2kW), pressure
compensating valve
Switch, two sockets Bel-
gian/French standard (max. 2kW), pressure
compensating valve
Switch, two sockets Ger-
man/Austrian standard (max. 3kW)
Cable H07BQ-F 2 x 1.0mm
2
red
H07BQ-F 3G1.5mm
2
red
H07BQ-F 3G1.5mm
2
red
H07BQ-F 3G1.5mm
2
red
Cable length 2.5m 2.5m 2.5m 5m
Earthed power outlet or shaped solid rubber plug
16A/250V∼ 16A/250V∼
with two earthing systems
16A/250V∼ with two earthing systems
16 A/250V∼ with two earthing systems
Operating temperature –20°C to +40°C –20°C to +40°C –20°C to +40°C –20°C to +40°C
Dimensions (height x width x depth)
250x 215x 155mm 250x 215x 155mm 250x 215x 155mm 320x 300x 125mm
Weight approx. 1,600g 1,800g 1,800g 2,300g

Würth MINI Specifications

General

Run Time	3 h
Luminous Flux	150 lm
Light Duration	3 h
Housing Material	Plastic
Length	163 mm
Power Source	Battery
