X-lite X-803RS - Disassembling the Top Flap; Disassembling the Side Flaps

28
X803 RS
WARNING
- Check that the side aps are correctly fastened to the support by gently pulling
their ends outwards and ensuring that they do not detach from the support.
- Check that the top ap is correctly fastened to the support by sliding it back and
forth (Fig. 40), and pull it slightly outwards to check that it does not detach from
the support.
3 DISASSEMBLING THE TOP FLAP
3.1 Push the top ap of the ASD forwards as far as it will go (Fig.40).
3.2 Pull one side of the top ap outwards until the lower tooth is released from the
guide on the support afxed to the shell. Repeat on the other side (Fig.42).
3.3 Pull the middle of the top ap outwards to completely remove it from the support
afxed to the shell (Fig.41).
4 DISASSEMBLING THE SIDE FLAPS
4.1 Push the lower end of the left side ap of the ASD towards the back of the helmet
until the grip pawl is released from the side seat on the upper support afxed to
the shell (Fig.43).
4.2 Repeat on the other side of the helmet to release the right side ap from the helmet.
INSTRUCTIONS FOR USE
