A-FRAME WEIGHT AND LOADINGS CAPACITY
The X-POLE A frame is a light weight, portable, frame which has been designed for home and light studio use for Aerial
Fitness.
The X-POLE A-Frame was not designed for professional performance use or dynamic drops.
The X-POLE A frame has been tested by the TUV International test house.
MBL ( Minimum Breaking Load) = 700kg
WLL ( Working Weight Load )
10:1 – 70kg/ 154lb
7:1 – 100kg/ 220lb
5:1 – 140kg / 309lb
No certication is possible as there are currently no international regulations for aerial tness equipment to certify against.
The X-Pole A-Frame is being used in a low level training environment and so X-Pole uses a factor of 5:1.
Carabiners
Copyright © Vertical Leisure Ltd. 2017 | All rights reserved. Version: 1.02
12
Note: Hammock method is shown using a daisy chain choked over the top bar.
Option: 3
Hammock
Daisy Chain
Hammock
Fig 2.7
