3. Name and functions of each part of the product
1
2
DC input port: It connects the power cable
enclosed in the kit.
Micro SD card slot: the Micro SD card
enclosed in the kit is inserted in the slot.
1
3
2
3
USB type turn signal connection port: It
connects the turn signal cable and video out
cable provided in the kit.
DC
12~24V
USB
Micro-SD
7
