9. Function description
(6) Video-out and turn signal connection (the cable can be offered at a cost.)
With the Video-out function, you can check video images real time on a screen device by connecting
K11 USB port and the import port of the screen via the Video-out cable additionally provided on your
option.
1.The provided Video- out cable is RCA type (male). It can be connected to a AV-IN RCA port of a
screen device.
2.The turn signal connection cable is all-in-one with Video-out cable. The turn signal cable comprises
three lines. Connect them with the signal lines (12V), which are normally placed under the driver’s seat.
Connect the black line with Ground and the rest two lines with the signal lines, respectively.
3.Once the turn signal cable is connected, in the LDWS mode when you change the lane with the
direction indicator on, an alarm does not sound.
(7) Security LED
① The front LED blinks when K11 detects a motion, giving a warning sign that the black box is being
recording.
30
(5) Constant recording
① In this mode, once power on, K11 keeps recording and the files are stored in the ―INFINITE‖
folder in the Micro SD card.
