PHT02_6/98

Tampa, FL33618 Mini Timer

™

Setting up the Mini Timer

To Dim and Brighten lights connected to a Lamp Module or Wall Switch Module, first

select the Module by pressing and releasing the ON rocker key for the desired Module,

then press the Bright or Dim rocker key. Hold the key pressed until the desired

brightness level is reached.

To turn on ALL lights connected to Lamp Modules and Wall Switch Modules (with same

Housecode as Mini Timer), press the All Lights On” key. This key does not affect

appliances.

To turn off ALL lights AND appliances connected to any kind of X-10 PRO

™

Module

(with same Housecode as Mini Timer), including Appliance Modules, press the “All

Units Off” key.
