X4-TECH SOI T8.5 - Page 2

B. ASPECT
1. Main Part
(1) Remote sensor
(2) Selecting DTV/ATV/AV source button
(3)ANS button
(to select Volume, Brightness, Contrast Colour, Tint )
(4) TV complex button
(up, down, right, left ,ok buttons)
(5) TV menu button
(6) Power (standby ) ON/OFF button
(7) Power indication
(8) Speakers
(9) LCD screen
(10) Antenna
(11) Set stand
(12) Video input socket
(13) Left/Right Audio input socket
(14) Earphone socket
(15) DTV audio video output socket
(16) DC power input socket(10~15V)
(17) Main power switch
(18) Screw hole
DTV:DVB-T digital TV
ATV: Analogue TV
DTV:DVB-T digital TV
ATV: Analogue TV
2
3
9
8
10
12
14
15
16
17
18
13
11
1 2 3 4 5 6 7
