X16plus Administration Manual
Page 5 of 54 Rev. 1.1.4
1. Introduction
The XBLUE X16
plus
business telephone system is a feature rich hybrid system delivering
BOTH standard business telephone system functions AND business VOIP system
functions. The XBLUE X16
plus
is capable of whatever technology best suits your needs.
X16
plus
delivers PBX features such as an auto-attendant, voice mail, multi-line
appearances, conference room with up to 16-parties if using one room only, intercom,
music on hold (BOTH file-based AND external source), call-forwarding and much more.
The X16
plus
is easy enough to configure that a fully working system can be set up in
minutes. In fact the default (factory) settings satisfy most applications without any changes.
X16
plus
is equipped with Plug and Play that allows XB IP9g and XB IP9g telephones to be
automatically detected and registered when they are connected. (They must be on the
same network.) The X16
plus
is easily managed and configured via an integrated web
server… You can program your X16
plus
using a PC and web browser!
1.1 Interfaces
◼ WAN Interface: one 10/100 Base-T Ethernet port (for connection to your
existing network)
◼ LAN Interface: one 10/100 Base-T Ethernet port (for creation of a closed
network)
◼ Digital Device Interface: 16 XD10/IP Phone (8 XD10/IP Phone + 8XD10/IP
Phone)
◼ CO Interface: 6 FXO (4 FXO + 2 FXO) for PSTN
◼ Power Fail CO backup: 1 (connects analog Line 1 to standby phone when
power fails)
◼ Page Out: 1
◼ MOH: 1
1.2 Capacities
◼ 16 Digital Extensions (8 standard, 8 optional)
◼ 16 IP Stations (optional VOIP Board required)
◼ 4 ~ 6 Analog Outside Telephone Lines (Trunks, CO Lines etc.)*
◼ 6 ~ 8 IP Trunk (optional VOIP Board required)**
* when the optional analog 2-Outside line expansion board is installed the
maximum SIP IP Trunks are 6
** when 8 SIP IP Trunks are used the maximum analog Outside Lines are 4.
