CHARGE ERROR TABLE: Errors 1-64: Flashing LEDs
0=OFF, 1=Flashing, S=Solid
Condition LED-1 LED-2 LED-3 LED-4 LED-5 Readable
Battery Over Voltage 0 0 0 0 1 1
Battery Temperature Low 0 0 0 1 1 3
Battery Temperature High 0 0 1 0 0 4
Battery Pack Unbalanced –V 0 0 1 1 1 7
Battery Pack Unbalanced –A 0 1 0 0 0 8
Batt Is 100% Discharged 0 1 0 0 1 9
Batt Beyond Over Discharged! 0 1 0 1 0 10
Batt Emergency Under-Voltage 0 1 0 1 1 11
Batt Temperature Sensor Open 0 1 1 1 1 15
Batt Temperature Sensor Shorted 1 0 0 0 0 16
Batt Over-Temperature 1 0 0 0 1 17
Battery Storage Error 1 0 0 1 1 19
Battery Testing Error – Sulphated 1 0 1 0 0 20
Battery Testing Error – Discharged 1 0 1 0 1 21
Bulk Charge Safety Time Error 1 1 0 0 1 25
Absorption Safety Time Error 1 1 0 1 0 26
Excessive Safety Time Error 0 0 0 0 1 32
Mode Selected Not Valid – Empty 0 0 0 1 0 33
Product Not Operational! 0 0 0 1 1 34
Lockout (Inhibit) Enable Defective 0 0 1 0 0 35
Lockout (Inhibit) Disable Defective 0 0 1 0 0 36
Internal Over Temperature 1 0 0 0 1 48
Finish Stage Exit via High Voltage S 0 0 0 1 ---
Equ. Stage Exit via High Voltage S 0 0 0 1 ---
Battery Over Voltage
o Charger’s Output DC Cable connection is possibly connected to a battery pack
with voltage higher than the output rating of the charger.
Battery Temperature Low/High
o If an external thermistor is connected in the application, the charger has detected
an attempt to use the battery out of its recommended temperature range… thaw
the battery if cold or cease charging and allow battery to cool down before
attempting to restart charge.
Battery Pack Unbalanced – V:
o Caused by unbalanced battery condition and or excessive battery plate
sulphation during Bulk Constant Current Stage. Example: some batteries are at a
much higher state of charge than others. This may require replacement of the
batteries. Refer to the Equipment’s Operators manual for instructions on
servicing the battery pack.
Battery Pack Unbalanced – A:
o Caused by an unbalanced battery condition during Absorption Constant Voltage
Stage. Inspect each battery with a load tester as well as observe if any battery is
‘hotter’ to the touch than other batteries in the pack. The indication is that a
cell(s) within the pack may have shorted, or experienced stratification of the
electrolyte (over-charging due to incorrect MODE setting) and may require
replacement of the batteries. Refer to the Equipment’s Operators manual for
instructions on servicing the battery pack.
