27
KIT No. PARTS DESCRIPTION Item No(s)
IPCJ0014-L000457 Input A.C. Cable; SJT-18/3, 18in ( 457mm) IEC_Right_Conn & 5-15P Plug Not Shown
IPCJ0014-L001830 Input A.C. Cable; SJT-18/3, 72in (1830mm) IEC_Right_Conn & 5-15P Plug Not Shown
KITS0180 120V PCB Controller Board – 24V with PCB Clips 1,9,10,18,19
KITS0181 230V PCB Controller Board – 24V with PCB Clips 1,9,10,18,19
KITS0182 120V PCB Controller Board – 36V with PCB Clips 1,9,10,18,19
KITS0183 230V PCB Controller Board – 36V with PCB Clips 1,9,10,18,19
KITS0184 120V PCB Controller Board – 48V with PCB Clips 1,9,10,18,19
KITS0185 230V PCB Controller Board – 48V with PCB Clips 1,9,10,18,19
KITS0186 Back Panel & Fan (Mounting leg and tie, not included) 11,12
KITS0187 Front Panel & LED Label, P-Clamp (Lockout/CVP via Bushing), Cable Bushing 2,3,4,6,15
KITS0188 Front Panel & LCD Label, Cable Bushing, P-Clamp (Lockout/CVP via Bushing) 2,3,4,6,15
KITS0191 *Plastic Body Cover Wrap with ID Label – read note below ‘*’ 8,20,21
KITS0192 Mounting Legs and Miscellaneous Hardware Package 5,17,13
KITS0193 AC Cord Tie 16
KITS0194 LCD Display Module (Small) and LCD-Cable Not Shown
*NOTE: I.D. Label must be returned to DPI and received by DPI prior to releasing
replacement part. Due to UL/CSA requirements, an ID Label affixed to a
replacement part cannot be sent out without verification that the previous
label has been destroyed.
For Input Cabling and Output Cabling options, contact distribution, OEM Supplier, DPI’s
web site, www.DPIpower.com and also refer to the section ‘Cables, Adaptors &
Accessories’ for some of the Cabling configuration options.
