The charger has 32 Charge Algorithm Modes available. Each mode is set to
charge a particular Battery Pack AND MUST BE SET CORRECTLY IN
ACCORDANCE WITH THE FOLLOWING TABLE:
‘CHARGE MODE SETTING TABLE’:
MODE – Switch Setting: 0 = Switch Up ( or left if vertically orientated )
1 = Switch Down ( or right if vertically orientated )
Switch Setting is numbered left to right or up/down ‘1’ to ‘5’
Mode Battery Name Type AH Range Absorption Switch Setting (Numbered)
Voltage* 1 2 3 4 5
01 Crown CR-225 Flooded 200-250AH 2.380V 0 0 0 0 0
02 Exide GC-135 Flooded 200-250AH 2.400V 0 0 0 0 1
03 JCI 6V-GC2 Energizer Flooded 210-260AH 2.450V 0 0 0 1 0
04 Trojan T105 Flooded 200-250AH 2.400V 0 0 0 1 1
05 Trojan T1275 Flooded 130-170AH 2.400V 0 0 1 0 0
06 Trojan L16G-AC Flooded 355-425AH 2.400V 0 0 1 0 1
07 USBattery US1800 Flooded 190-235AH 2.450V 0 0 1 1 0
08 USBattery US2200 Flooded 205-260AH 2.450V 0 0 1 1 1
09 Full River DC220-6 AGM 195-245AH 2.450V 0 1 0 0 0
10 Full River DC335-6 AGM 305-365AH 2.450V 0 1 0 0 1
11 GNB M83CHP06V27 AGM 170-220AH 2.330V 0 1 0 1 0
12 Trojan T105 Reliant AGM 210-230AH 2.450V 0 1 0 1 1
13 USBattery US2224 AGM 200-250AH 2.400V 0 1 1 0 0
14 Trojan 6V-GEL GEL 165-215AH 2.333V 0 1 1 0 1
15 PsZ-Cell – Lead Acid Flooded 075-125AH 2.400V 0 1 1 1 0
16 PsZ-Cell – Lead Acid Flooded 125-175AH 2.400V 0 1 1 1 1
17 PsZ-Cell – Lead Acid Flooded 200-250AH 2.400V 1 0 0 0 0
18 PsZ-Cell – Lead Acid Flooded 300-350AH 2.400V 1 0 0 0 1
19 PsZ-Cell – Lead Acid AGM 075-125AH 2.450V 1 0 0 1 0
20 PsZ-Cell – Lead Acid AGM 125-175AH 2.450V 1 0 0 1 1
21 PsZ-Cell – Lead Acid AGM 200-250AH 2.450V 1 0 1 0 0
22 PsZ-Cell – Lead Acid AGM 300-350AH 2.450V 1 0 1 0 1
23 General – GEL GEL 075-125AH 2.333V 1 0 1 1 0
24 Enersys 12XFC82 Pure Lead 075-125AH 2.450V 1 0 1 1 1
25 General – Pure Lead Pure Lead 200-250AH 2.433V 1 1 0 0 0
26 General – Pure Lead Pure Lead 300-375AH 2.433V 1 1 0 0 1
27 Optima OPT-D31M Spiral 050-100AH 2.450V 1 1 0 1 0
28 General – Spiral Lead Spiral 130-170AH 2.450V 1 1 0 1 1
29 Sony LiFePO4 Cell Li+ 055-065AH 4.172V 1 1 1 0 0
30 Sony LiFePO4 Cell Li+ 190-210AH 4.172V 1 1 1 0 1
31 BMZ LiFePO4 Cell Li+ 160-175AH 4.175V 1 1 1 1 0
32 Empty/User Configured User N/A 1 1 1 1 1
*NOTE: The Absorption Value is listed as Volts Per Cell and is one of the most important
parameters pertaining to that charge algorithm. Different battery packs have differing
number of cells – multiply the number of cells times the ‘Volts-Per-Cell’ value to obtain the
voltage the charger will regulate during the Absorption Charge Stage. For example; using
MODE-2 ‘Absorption Voltage value of 2.400V/cell’ from the table above:
12V Battery Pack = 6 Cells Absorption = 14.40Vdc
24V Battery Pack = 12 Cells Absorption = 28.80Vdc
36V Battery Pack = 18 Cells Absorption = 43.20Vdc
48V Battery Pack = 24 Cells Absorption = 57.60Vdc
72V Battery Pack = 36 Cells Absorption = 86.40Vdc
For Lithium Battery MODES and using MODE-31 as the example:
12V Battery Pack = 3 Cells Absorption = 12.52Vdc
24V Battery Pack = 7 Cells Absorption = 29.22Vdc
36V Battery Pack = 11 Cells Absorption = 45.92Vdc
48V Battery Pack = 14 Cells Absorption = 58.44Vdc
72V Battery Pack = 21 Cells Absorption = 87.66Vdc
