XCell Fury Extreme Assembly Manual

Created: 11/14/2006 Copyright Miniature Aircraft USA Page 105 of 138

This document may not be distributed without permission of Miniature Aircraft USA

8D.1 – Assemble/Install Flybar Control System

Rod Lengths

8D.1.a 8D.1.b 8D.1.c

Completed

Control

Rods

Prints

Actual

Size

#0337

#0133 (2)

9mm

#0135

#0313

61 mm

#126-88

#0555-1

#0053-5

10mm

#126-88

Swash

late

Bell

Flybar Control

Flybar/Bell
