XS9900D Xcruiser Satellite-Meter ENG- 42
LNB/Tuner input
F-type connector IEC 169-24
Frequency range 950 MHz ~ 2150 MHz
Input level -65 dBm bis -25 dBm
LNB power supply 13/18 V, max. 400 mA
LNB control signal 22 kHz
DiSEqC control Version 1.0
Demodulator
Front-end-module
QPSK
Symbol rate 1,5 Mbps bis 45 Mbps
SCPC- und MCPC
Spectral inversion Auto conversion
System resource
Processor 32 bit
SDRAM 16 MByte
FLASH 2 MByte
EEPROM 8Kbyte
Vide decoder
Data rate up to 15 Mbit/s
Resolution 720 x 576 (PAL), 720 x 480
(NTSC)
Video format PAL, NTSC, SECAM
Connectors
Serial data interface
USB (Type A)
Power supply
Supply voltage 12,6 V
Li-oN battery 1950 mA
Charger 90 – 240 V
Supply voltage (charger) 175 - 250 V ~, 50/60 Hz
Dimensions
Length x width x height 9,5 x 15,5 x 4,5 cm
Gross-weight 0,5 Kg
Temperature
Operating temperature 0°C to +40°C
Storage temperature -40°C to +65°C
