xDEEP Ghost User Manual

7 Optional trim pockets
Although GHOST system provides perfect trim in most of the suits, in some cases (e.g. dry suit with very thick
undersuit) you may need to have the weight distributed in a special manner. Depending on the needs, you can
install additional trim pockets thanks to which you get the optimal distribution of the centre of gravity,
regardless of the type of suit you use. Together with GHOST system you can use the following types of trim
pockets:
 Standard trim pockets placed on straps to attach the tank or on additional strap of equal type placed
anywhere on the tank (e.g. on tank stand):
 Trim pockets of STEALTH 2.0 sidemount system which can be placed anywhere on the crotch strap -
useful in case you are turned upside down:
 Trim pockets fixed permanently to the plate using proper holes (marked with a rim):
Fig. 5. Standard trim pockets
Fig. 6. Trim pockets of STEALTH 2.0 system
Fig.7. Mount points of pockets to the plate

xDEEP Ghost Specifications

General

Material	Nylon
Wing Type	Donut
Type	Backplate and Wing System
Wing Lift Capacity	17 kg (37 lbs)
Inflator	K-style inflator
Configuration	Single Tank
Backplate Material	Aluminum or Stainless Steel
Wing Material	Cordura
