2. Use only the charger which is provided by Xenosys on the phone jack. This may cause the
defective on the charger and DC power supply.
WARNING for Disposal
1. In case of careless disposal, it may pollute the environment, so make sure to separate
collection.
Features
1. Operating Principle
L2SX5 adopts the way to deliver DC voltage from the battery to LED device through STEP-
Down circuit and generate light speed through the lens. Even though battery voltage is
reduced, L2SX5 allows LED to provide consistent brightness.
2. Electrical Rating
1) Battery pack: DC3.6V 6700mAh (Lithium Ion)
2) Charger: Input DC5V 2200mA / Output-DC4.2V 2000mA
3) Medical power supply: Input AC100-240V, 50-60Hz, 0.3A / Output DC5V, 2200mA
3. Protection Classification & Type against Electric Short
1) Protection Classification: ① Battery pack: Internal powered device
② Charger, Power supply: Class II device
2) Protection Type: N/A
4. Safety Circuit: L2SX5 contains the protection circuit for over current & overvoltage to keep
the charging quantity.
5. Block Diagram: Refer to below figure
