22 Xerox Nuvera, iGen Production System Production Media Cart
Production Media Cart User Guide
Docking the Xerox Production Media Cart with the Xerox iGen Stacker
Pallet with Power Eject Kit
It is recommended that you first practice docking the Production Media Cart (Cart) without a
paper stack loaded.
Warning
Do not exceed the load capacity of 160 lbs. (72.6 kg) to avoid personal injury and damage to
the Cart.
1. Open the front door of the stacker module.
2. Set the Media Cart to the appropriate height.
a. Locate the line on the cart post that corresponds to the iGen stacker height of 103 mm.
b. Press the elevation button to match the short lines on the sides to the line on the cart
post.
Line up pointer to hole
Elevation button
