Xerox
®
WorkCentre
®
5845/5855
Detailed Specifications 3
Dimensions and Weight Width Depth Height Weight
Base Configuration with
OCT
39.0 in. / 990 mm 25.6 in. / 650 mm 43.5 in. / 1,104 mm 271.8 lbs. / 123.3 kg
With Basic Office Finisher
(5845 only)
47.6 in. / 1,209 mm 25.6 in. / 650 mm 43.5 in. / 1,104 mm 319.7 lbs. / 145 kg
With Office Finisher 47.6 in. / 1,209 mm 25.6 in. / 650 mm 43.5 in. / 1,104 mm 329.6 lbs. / 149.5 kg
With Office Finisher with
Booklet Maker
47.6 in. / 1,209 mm 25.6 in. / 650 mm 43.5 in. / 1,104 mm 364.9 lbs. / 165.5 kg
With High Volume
Finisher
64.8 in. / 1,645 mm 25.6 in. / 650 mm 45.1 in. / 1,145 mm 425.1 lbs. / 192.8 kg
With High Volume
Finisher with Booklet
Maker, C Fold / Z Fold
Unit and Post Process
Inserter
78.5 in. / 1,995 mm 25.6 in. / 650 mm 46.5 in. / 1,180 mm 485.7 lbs. / 220.3 kg
High Capacity Feeder 15.3 in. / 389 mm 20.1 in. / 510 mm 22.6 in. / 510 mm 66.1 lbs. / 30 kg
Work Surface (Does not
add to overall width if
combined with High
Capacity Feeder
11.2 in. / 285 mm – – –
Certifications
FCC Class A Compliant (US), ICES Class A Compliant (Canada)
CSA Listed (UL 60950-1, Second Edition)
CB Certified (IEC 60950-1, Second Edition)
ENERGY STAR
®
GOST
NOM
Environmental Choice
CE Marked
Common Criteria (IEEE 2600.2 standard)
EPEAT
GS Mark
Citrix
®
Certified
WHQL
MEDITECH
Cerner
To view the latest list of certifications, go to www.xerox.com/OfficeCertifications.
Paper Handling
Single-pass Automatic Document Feeder
Capacity
3
200 sheets
Speed (black-and-white
and color)
Up to 105 images per minute (ipm) (simplex)
Up to 200 ipm (duplex)
Paper Sizes Sensed 4.9 x 5.4 in. to 11.7 x 17 in. / 125 x 138 mm to 297 x 432 mm
Weights 13 lb. bond to 43 lb. bond / 50 gsm to 160 gsm
Bypass Tray
Capacity
3
100 sheets
Sizes Custom sizes: 4.25 x 5.5 in. to 11 x 17 in. / A6 to A3
Weights 16 lb. bond to 80 lb. cover / 60 to 216 gsm
