1.4 As the next connection the +12 V cable has to be connected to the (+) terminal of the battery.Always be careful not to run this cable
around sharp edges, the insulation might be damaged. For holes always use grommets!
Always use an in-line fuse in the +12 V power cable in max. 12" from the battery’s + terminal (value must meet the
current requirements of the whole sound system, minimum value is 60 A).
1.5 The last connection is the remote wire.The head unit must always be turned off during this connection, as it might be damaged when
remote output is shorted to ground! Now you can reconnect the battery and insert the main fuse into the power cable’s fuse holder.
CAUTION: Both, the +12 V and the ground cable, must have sufficient diameter!
XETEC proposes the following minimum gauges:
Total output power of the system:
Up to 100 W : 6 mm2
Up to 250 W : 8 mm2
Up to 500 W : 10 mm2
Up to 750 W : 25 mm2
Up to 1000 W : 35 mm2
Up to 1200 W : 40 mm2
More than 1200 W : 50 mm2
Weaker Cables will reduce the performance of your system significantly,and may cause damage to your amplifiers.Weak cables also will
heat-up!
Caution:Always replace fuses with same value. Higher values may cause damage to your amplifier, battery or car!
2. First power-on:
2.1 Adjust all level controls to minimum
2.2 Turn on the radio at low volume
2.3 Increase the volume and adjust the front speaker’s volume
2.4 Now adjust the volume ratio between front and rear speakers and subwoofer.
– 6 –
