FUZHOU CANWELL IMPORT & EXPORT CO., LTD.
4
Tel:0086-591-87610093, 87614264 Fax:0086-591-83640189,87279269 E-mail:qqmd@fcanwell.com
4 Specs.
Content Specs.
Dim. 85mm x 63mm x 25mm(3.3”*2.5”*0.98”)
Weight 50g
Network GSM/GPRS
Band 850/900/1800/1900
GPS chip SIRF3 chip
GSM/GPRS module Simcom900
GPS sensitivity -159dBm
GPS accuracy 5m
Time To First Fix Cold status 45s Warm status 35s Hot status 1s
Car charger 12—24V input 5V output
Wall charger 110－220V input 5V output
Battery 3.7V 800mAh Li-ion battery
Standby 8hours
Storage Temp. -40°C to +85°C
Operation Temp. -20°C to +55°C
Humidity 5%--95% non-condensing
5 Usage
5.1 SIM card installation
Make sure that there is no call transfer and call display is on, and PIN code off. The SMS
message must in Text format, can’t be identified for PDU format.
5.1.1 Put SIM card into card box.
5.1.2 Put the card box into host as picture.
.
