1. Connect the black power wire of the BMS to the negative lead of the battery pack.
2. Connect the red power wire of the BMS to the positive lead of the battery pack.
3. Connect the balancing wires in order, starting with B0 and finishing with B10.
4. Install temperature sensors and thermal fuse using a thermal compound or neutral sealant with thermal
grease.
5. Solder the connector that comes with the BMS to the rear light wire.
6. Connect the battery to the scooter.
7. To start the BMS for the first time, connect the charger to the scooter. In case of a successful start, the
indicator LED will blink on the board.
7
