Xiaomi Router AX3200 User Manual

2
Configuring the Network
WLAN
WLAN
xiaomi-router-rb01_miapxxxx
xiaomi-router-rb01_miapxxxx_5G
* If the configuration page is not present, open the browser and go to
router.miwifi.com to complete the configuration.
* See the nameplate on the boom of the router for the initial Wi-Fi
name.
router.miwifi.com
Thank you for using Xiaomi Router
Start
1. When the router's system indicator turns blue, use your
phone or computer to connect with the initial Wi-Fi.
2. Once the initial Wi-Fi is connected, you will be directed to
the configuration page. Follow the instructions on the page
to complete the configuration process.

Xiaomi Router AX3200 Specifications

General

Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power
Antennas quantity	6
Internal memory	256 MB
Processor cores	2
Processor model	Filogic800
Built-in processor	Yes
Processor frequency	1350 MHz
Processor architecture	ARM Cortex-A53
Processor manufacturer	MediaTek
Modulation	BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	1000 Mbit/s
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Mobile operating systems supported	Android, iOS
Security algorithms	WPA-PSK, WPA2-PSK, WPA3-SAE
DSL WAN	-
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN interface type	Gigabit Ethernet
Power source type	AC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	186 mm
Width	284 mm
