V5 series inverter
93
START Keep no signal input > =10ms
Address Communication address: 8-bit binary address
Function Function code: 8-bit binary address
DATA (n - 1)
Data:
N*8-bit data, N< =8, Max=8 bit
……………
DATA 0
CRC CHK Low CRC parity code
CRC CHK High 16-bit CRC parity code is combined by 2 8-bit binary value
END Keep no signal I/O > =10ms
2. Communication address:
00H: broadcast for all the inverters（broadcast）
01H: communicate with the inverter addressed 01
0FH: communicate with the inverter addressed 15
10H: communicate with the inverter addressed 16
………., max can reach 254（FEH）
3. Function code and Data:
Function code Explanation
03H Read register, read multi-register once (register less than 31), can read the same group of data every
time
06H Write data to register
08H Circuit test
10H Write multi-group data to register
(1) Function code 03H: read register
For example: Read address 2104H (Output current）
RTU Mode:
Request mode Response mode
Address 01H Address 01H
Function code 03H Function code 03H
Register address
21H
Byte No. 02H
04H
Register No.
00H
Dada
00H
01H 00H
CRC CHECK Low CFH CRC CHECK Low B8H
CRC CHECK High F7H CRC CHECK High 44H
(2) Function code 06H: Write to register
For example: 01H, write function code P0.02=50.00HZ.
RTU Mode:
Request mode Response mode
Address 01H Address 01H
Function code 06H Function code 06H
Register address 00H Register address 00H
To Next Page
