V5 series inverter
35
4 Function Parameters
4-1. Function code
○: Parameters can be changed while running
×: Parameters can not be changed while running
* : Parameters can only be read, can not be changed
1. Basic running parameters (Group P0)
Group P0: Basic running parameters
Parameter Name Setting Range
Minmum
unit
Default setting Change
P0.00 Control mode
selection
0: V/F control
1: open-loop vector control
1 0 ×
P0.01 Frequency setting
mode
0: potentiometer on the panel
1: Increase/Decrease key
2: digital setting 1, via keys on the
panel
3: digital setting 2, via terminal
UP/DOWN
4: digit setting 3, via serial port
5: VI analog input (VI-GND)
6: CI analog input (CI-GND)
7: Pulse input (PULSE)
8: Combined setting mode (refer
to P3.00)
1 0 ○
P0.02 Digital set the
running frequency
P0.19 max frequency ~ P0.20 min
frequency limit
0.01HZ 50.00HZ ○
P0.03 Running command
selection
0: operation panel
1: Teminal
2: serial port
1 0 ○
P0.04 Running direction
setting
Lowest bit:
0: jog forward via panel
1: jog reverse via panel
Ten bit:
0: enable to reverse running
1: prohibit reverse running
1 00 ○
P0.05 Run forward/reverse
dead zone time
0.0~120.0s 0.1s 0.1s ○
P0.06 Highest ouput
frequency
50.00Hz~500.00Hz 0.01Hz 50.00Hz ×
P0.07 Basic running
frequency
1.00Hz~500.00Hz 0.01Hz 50.00Hz ×
P0.08 Highest output
voltage
1~480V 1V Inverter rated
voltage
×
P0.09 Torque boost 0.0%～30.0% 0.1% 2.0% ○
P0.10 Cut-off frequency
for torque boost
0.00Hz~basic running frequency
P0.07
0.00 25.00Hz ○
P0.11 Torque boost mode 0: manual
1: automatic
1 0 ○
P0.12 Carrier frequency 1.0K~14.0K 0.1K 8.0K ×
P0.13 Acc/Dec mode
selection
0: linear Acc/Dec
1: S curve Acc/Dec
1 0 ×
P0.14 Low speed time of
S curve
10.0%~50.0% (Acc/Dec time)
P0.14＋P0.15＜90%
0.1% 20.0% ○
