1-1．Products Specifications
1-1-1．CPU Units
XC series PLC's CPU units has many subsidiary products line, the combination can be make
freely.
l I/O Points: 10、14、16、24、32、48、60 points
l Output Type: Transistor、Relay、R/T mixed type
l Input Type: PNP、NPN
l Power Supply Type: AC220V、DC24V
l Subsidiary
※
1
XC1、XC2、XC3、XC5、XCM
Series Type Description
XC1 Economic Type
Include 10I/O、16I/O、24I/O、32I/O
Suitable for common simple applications which has less I/O
requirement, Do not support free communication, expansion, BD
cards.
XC2 Basic Type
Include 14I/O、16I/O、24I/O、32I/O、48I/O、60I/O
Equipped XC series PLC's basic functions, the CPU unit can't work
with expansions, but can work with BD card. Equipped with high
speed operation ability.
XC3 Standard Type
Include 14I/O、24I/O、32I/O、48I/O、60I/O
XC series standard models, equipped with full functions, fulfill the
user's diverse requirements
XC5 Strength Type
Include 24I/O、32I/O、48I/O、60I/O
Besides XC3 series functions, XC5 series PLC added following
functions:
24I/O, 32I/O models have 4CH pulse output;
48I/O, 60I/O support CAN-bus, users can realize CAN bus network
functions
XCM
Motion Control
Type
Include 24I/O、32I/O
Besides XC series basic functions, XCM models support powerful
pulse output functions and rich motion control instruction. The
models are designed especially for motion control.
l Special Type XC3-19AR-E (Combine analogue I/O with digital I/O in one body）
※
2
※1：For each subsidiary series's model list and functions, please refer to Appendix 4;
※2： XC3-19AR is not included in this manual. For the using method, please refer to《XC3-19AR-E manual》。
Diverse Models 1
