Xinje XC1-10R-E User Manual

8 expansion devices
24V +24V power supply
-
0V COM of power supply
8-3-2．XC-E4AD2DA
Analogue Input Analogue Output
Items
Voltage Input
Current Input
Voltage
output
Current Output
Analogue Input Range 0~5V,0~10V 0~20mA,4~20mA -
Max Input Range
DC±18V
0~40mA
-
Analogue Output Range -
0~5V、0~10V,
(external load
resistor
2KΩ~1MΩ)
0~20mA,4~20mA
(external load resistor
500Ω)
Digital Input Range - 12bits binary (0~4095)
Digital Output Range 14 bits binary (0~16383) -
Distinguish Ratio
1/16383(14Bit); the convert data is
stored in PLC in form of Hex. (14Bit)
1/4095(12Bit); the convert data is stored
in PLC in form of Hex. (14Bit)
PID Output Value 0~K4095
Integral precision 0.8%
Convert Speed 20ms/CH 3ms/CH
Power Supply DC24V±10%, 100mA
l 4CH analogue input: voltage and current input selectable; Voltage input range is 0～5V、
0～10V selectable, current input range is 0～20mA、4～20mA selectable;
l 2CH analogue output: voltage and current input selectable; Voltage input range is 0～5V、
0～10V selectable, current input range is 0～20mA、4～20mA selectable;
l 14 bits high precision analogue input;
l As the special module, 7pcs XC-E4AD2DA can be connected to one XC series PLC main
unit;
Brief Introduction 1
Specification 2
