Xirgo Technologies XT4964 - Hardware Description

5
2 Hardware Description
Below is a depiction of key interfaces of the XT4964:
The Associated Cable Harness that interfaces with the unit is shown below:
Solar Panel
Device/FCC Label
Wake-up
Button
8-Pin Bayonet
Connector
Gore Vent
LED Indicators
