AppendixE PARAMTERTABLE
Acceleration event
thresholds
8
aet
4
<direction (adlr)> <start_duration> <end_duration> <mg_thresh>
Accelerometer report
correction
1
arc
1
<correction_factor>
APNs
4
apn
3
"<apn_name>" "<username>" "<password>"
Crash event params
1
cep
3
<mg_thresh> <poll_freq> <hist_depth>
Debounce settings
6
idb
2
<on_sec> <off_sec>
Destination
10
dst
2
"<ip>|<hostname>" <port>|<serial_port_id>
ECU_Thresholds
1
vth
4
<brake_thresh> <accel_thresh> <speed_limit> <rpm_limit>
Flag save mask
1
fsm
1
<32bit_mask>
Garmin Blacklist
16
gbl
5
<flags> <pid> <size> <byte0> <byte1> (see example below)
Geofence
50
gfn
3
<lat> <lon> <radius>
Input default polarity
4
idp
1
<pullup_disable> (0=active_low,1=active_high)
Ignition sense
1
ign
3
<source mask> <ign on sec> <ign off sec>
MIP/SIP Control (TBD)
1
mip
1
<value>
Motion sensitivity
1
mst
1
<motion_sensitivity_value>
NMEA stream output
4
nso
1
<8bit_mask> (see NMEA mask below. One param for each of the 4
serial outputs)
Odom Ign Off accum
2
oio
1
<accum>
Packet Creation Append
16
pca
1
"<append_hex_string>"
Packet Creation Recipe
128
pcr
1
"<recipe_hex_string>"
Packet Retry
2
prt
1
<sec>
Serial port settings
2
sps
2
<baudrate> "<dps>"
Timer duration
32
tmr
2
<sec> <auto_start>
OBD RPM and Speed
2
ors
2
<rpm threshold> <rpm time sec> <mph threshold> <mph time sec>
OBD Accel and Decel
2
oad
1
<obd accel> <obd decel> (1mph/sec, 1mph increments)
Variable save mask
1
vsm
1
<32bit_mask>
NMEA mask
One bit for each of the available NMEA sentences. Values can be added to stream more than one sentence type. Set mask to zero to stop
streaming.
GPGGA 0x01
GPGLL 0x02
GPGSA 0x04
GPGSV 0x08
GPRMC 0x10
