XR-2425H Q uic k Insta lla tio n Guid e
- 1 1 -
Dimensions
XR-2425H Dimensions
Depth is 4.2 in (10.7 cm), including the
mounting bracket.
Weight: 7.5 lbs (3.4 Kg)
Mounting Bracket Dimensions
Depth = .5 in; 1.3 cm
11.4 in
28.9 cm
11.8 in
30 cm
13.3 in
33.7 cm
3.2 in
8.1 cm
