Part Name:
A front bike frame A-1 rear bike frame B handlebar
E Allen Key C front fork assembly D saddle
①pair of
lock screws
② bike
frame buckle
Installation Instructions:
First, insert the rear frame A-1 into the front frame A in the direction of the
dotted arrow. When inserting, pay attention to align the hole positions of
the two frames, then insert the locking screw ① and use the tool to lock.
① locking
screw
C1.pedal fixture
