XJD KF-T02 - Operating Instructions; How to Unfold the Tricycle; How to Fold the Tricycle

How to unfold
Fig.1 Fig.2
Fig.3 Fig.4
Step 1: Pull out the fork
blade fasteners (A-1②).
Step 2: Take the pedal off
the fixture, and insert it into
the front wheel to remove
the ejector. Then press the
frame button (a) to open the
rear leg. Make sure the rear
leg is opened fully so that
the button can be ejected.
Step 3: Insert the fork blade fasteners (A-1②) into the rear leg (as shown in the figure).
Step 4: Press the button of the rear wheel, rotate the left/right rear wheel outward in place.
How to fold
Fig.1 Fig.2
Fig.3 Fig.4
1. Step 1: Press the button
of the rear wheel, rotate the
left/right rear wheel inward
in place.
2. Step 2: Pull out the
fasteners of the frame (A-1).
3. Step 3: Take the pedal off
the front wheel, and insert it
into the pedal fixture (C1)to
remove the ejector. Then
press down the frame button
to close the rear leg. Make
sure the rear leg is closed
fully, and then press button
to remove it.
4. Step 4: Insert the fork blade fasteners (A-1) into the rear leg (as shown in the figure).
