COMMON INSTALLATIONS
www.xoappliance.com
It is essential for proper operation that the Disposer drain completely when not in use. For that reason,
minimum distances “A” between the bottom of the sink and the drain outlet must be maintained.
BATCH FEED MODELS - minimum height clearance 10”
CONTINUOUS FEED MODELS - minimum height clearance 8”
SINGLE BOWL DOUBLE BOWL DOUBLE BOWL
CENTER OUTLET END OUTLET
BATCH FEED MODEL DIMENSIONS
9 29/64"
18 1/16"
4"
Ø1 1/2"
7 41/64"
9 11/64"
16 49/64"
4"
Ø1 1/2"
6 37/64"
t
6 7/32"
13 13/16"
4"
Ø1 1/2"
5 11/16"
7 3/16"
15 3/4"
4"
Ø1 1/2"
7 5/8"
6 31/32"
14 9/16"
4"
Ø1 1/2"
6 3/4"
CONTINUOUS FEED MODEL DIMENSIONS
XOD12HPBF
XOD34HPBF
XOD1HPBF
XOD12HP
XOD34HP
XOD1HP
XOD12BUILDER
“A” “A”
“A”
