4.16 the factory menu adjustment model pre-set
OSD item Pre-set model
P1-60
V SIZE 60HZ field amplitude 63 4.9
V SHIFT 60HZ field center 0 4.9
H-PHASE 60HZ H-center 15 4.9
V LINE 60HZ V-line 15 4.9
V SC 60HZ field S-correct 23 4.9
V COMP field amplitude compensate 7 fixed
L.BLK Left blanking 7 fixed
R.BLK Right blanking 0 fixed
P2-EW-60
COR.SW margin correct 1 Fixed
H.SIZE.COMP High voltage compensate 7 fixed
TILT 60HZ echelon correct 44
DC 60HZ H-amplitude 32
AMP 60HZ pincushion correct 25
COR.TOP 60HZ Top margin correct 4
COR.BOT 60HZ bottom margin correct 3
Receive signal A12, adjust the linearity scanning and
geometric distortion and over-scanning coincide with it
P3-50
V SIZE 50HZ field amplitude 75 4.10
V SHIFT 50HZ field center 0 4.10
H-PHASE 50HZ H-center 10 4.10
V LINE 50HZ V-line 16 4.10
V SC 50HZ field S-correct 20 4.10
P4 EW-50
TITL 50HZ echelon correct 49
DC 50HZ H-amplitude 35
AMP 50HZ pincushion correct 41
COR.TOP 50HZ Top margin correct 6
COR.BOT 50HZ bottom margin correct 10
Receive signal G35, adjust the linearity scanning and
geometric distortion and over-scanning coincide with it
P5
LINE Level bright line 0 0=normal 1= Level bright line
RB Red cut off 100 4.4
GB Green cut off 100 4.4
BB Blue cut off 100 4.4
RD Red driver 100 4.4
GD Green driver 15 4.4
BD Blue driver 100 4.4
P6
RF AGC RF AGC 30 4.3
SUB-BRI Sub-brightness 60 4.4
SUB-CNT Sub-contrast 31 fixed
