6
SUB-COL Sub-colour 3 fixed
SUB-SHP Sub-definition 0 fixed
SUB-TINT Sub-tint 28 fixed
P7
VOL.FIL Volume control ADC filter 0 fixed
OSD.COT OSD contrast 5 fixed
OSD.HPOS OSD center 10 fixed
AFT
Line AFC loop gain and sync
gate switch
0
fixed
VIF SW IF3=45.75MHZ 3 fixed
SIF SW Sound IF0=4.5MHZ 0 fixed
VIDEO LEVEL VIDEO LEVEL 2 fixed
P8
A2 .SW 0 fixed
GY ANGLE G-Y demodulation angle 0 fixed
V.R TM Filed scan strting time 0 fixed
R/B ANG R-Y/B-Y demodulation angle 8 Fixed
R/B BAL
R-Y/B-Ydemodulation
balance
8 fixed
C TRAP Color trap filter 6 fixed
H FREQ H-frequency 16 fixed
C.BPF TEST
Color band filter center
frequency
0 fixed
P9
OVER.MOD.SW
Selection over-modulation
function
0 Fixed,0=nothing 1=have
OVER.MOD.LVL
Adjustment over-modulation
working point
0 fixed
BLK.STR
Dark level expand starting
control point
2 Fixed,0=40IRE 2=60IRE 3-OFF
BLK.GAIN Dark level expand gain 2 Fixed,0=MIN 2=MAX
Y.APF Selection color trap filter 1 0=trap filter,1= direct pass(YcbCr&Y/C)
PRE.ADJ Pre-shoot 3 fixed, 0=narrow 3=width
OVER ADJ overshoot 3 Fixed,a 0=narrow 3=width
C.VCO.ADJ
Color VCO frequency
adjustment
4 fixed,0－4－7=-120KHZ-0-90KHZ
P10
BRT.ABL.DEF Brightness ABL 0 fixed,0=ABL ON 1=ABL OFF
MID.STP.DEF ABL start control point 0 fixed
BRT.ABL.THR ABL threshold 7 fixed
WPL.OPE White peak limit 2 fixed
V BLK.SW Field blanking switch 0 fixed ,0=nomarl;1=width model
