English - 7
Breathing Hole
WARNING
• Do not tape or block the breathing holes on
the tapered flow nozzle and the air pump
adapters.
• The breathing holes allow the machine to
release the air pressure when the straw
adapter or the detail brush is blocked.
• Blocking the breathing holes could cause
serious failure on the machine and void the
warranty.
Nozzle Installation (Continued)
!
The tapered flow nozzle, straw
adapter and the detail brush should
be used together.
Tapered Flow Nozzle
• Attach the straw adapter onto the
tapered flow nozzle.
Straw Adapter
• Insert the detail brush inside the
other end of the straw adapter.
Detail Brush
• Attach the whole set of the nozzles
onto the Cyber Duster.
