21
903412
SFH M4x12
6. F&R ASSEMBLY
351232 COMPOSITE FRONT & REAR SUSPENSION HOLDER PLATE
353083 COMPOSITE REAR BRACE
902325 HEX SCREW SH M3x25 (10)
903412 HEX SCREW SFH M4x12 (10)
BAG
351232
351133 GTXE
351134 GTX8
903412
903412
960030
960040
902325
353083
960030 NUT M3 (10)
960040 NUT M4 (10)
351133 GTXE.3 ALU CHASSIS - SWISS 7075 T6 (3MM)
351134 GTX8.3 ALU CHASSIS - SWISS 7075 T6 (3MM)
902312
#353281
GT GRAPHITE BRACES FOR REAR COMPOSITE BRACE - SET
960030
353281
353281
GTX8GTXE
