31
901404
SB M4x4
901405
SB M4x5
930816
BB 8x16x5
903306
SFH M3x6
8. CENTER SOLID SHAFT & MOTOR
THREAD
LOCK
THREAD
LOCK
THREAD
LOCK
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
NOTE
ORIENTATION
CUTAWAY VIEW
4x4mm
4x4mm
4x5mm
GRAPHITE GEARS
#345648 48T OPTION
#345649 49T OPTION
#345650 50T OPTION
COMPOSITE GEARS
#345548 48T OPTION
#345549 49T INCLUDED
#345550 50T OPTION
GRAPHITE GEARS
#345648 48T OPTION
#345649 49T OPTION
#345650 50T OPTION
COMPOSITE GEARS
#345548 48T OPTION
#345549 49T INCLUDED
#345550 50T OPTION
GTXE
Ball-bearing with STEEL covers
Ball-bearing with STEEL covers
Use HUDY Ball-Bearing
Grease or Oil for servicing:
#106220 - Standard
#106221 - Extra
#106222 - Premium
#106230 - Bearing Oil
#354011-G
CENTER DIFF MOUNTING PLATE - SET
