38
10. RADIO CASE
902312
SH M3x12
902308
SH M3x8
902308
SH M3x8
907206
2x6
If the receiver box has 2 different-size openings
for cable entry (narrow and wider), cut away
the tab for the appropriate opening to allow the
cables to fit properly.
Receiver
(NOT INCLUDED)
Eccentric mount
Antenna
Servo Screw
(NOT INCLUDED)
NOTE
ORIENTATION
GTXE
