Xray GTX8 User Manual

47
SHOCK ABSORBERS
BOOK
SET-UP
SHOCK ABSORBERS
960030
N M3
960030
N M3
902319
SH M3x18
LEFT thread
902318
SH M3x18
901303
SB M3x3
902314
SH M3x14
SILICONE
TUBING
9mm
GTX8
SHORTER
LONGER
SHORTER
LONGER
On the front right arm use the SILVER M3x18
screw - this screw has LEFT THREAD
Use STANDARD
M3x18 screw
3x18mm
L=R
L=R
2x
2x
902319
SH M3x18
LEFT thread
960030
N M3
902318
SH M3x18
12. FINAL ASSEMBLY
On the rear left arm use the SILVER M3x18
screw - this screw has LEFT THREAD
Use STANDARD
M3x18 screw
M3x18mm
INITIAL SETTING
DETAIL
L=R
BOOK
SET-UP
NOTE
ORIENTATION
NOTE
ORIENTATION
INITIAL SETTING
DETAIL
L=R
Throttle rod
Thread brake rods into plastic
pivots until flush with outer end
Brake rod
Brake rod
Cut off remaining
material
Use servo horn to
match your servo
K - (23T)
H - (24T)
F - (25T)
INITIAL SETTING
DETAIL
L=R
CLAMP ALU SERVO HORNS
#293444 23T OPTION
#293445 24T OPTION
#293446 25T OPTION
#293447 23T OPTION
#293448 24T OPTION
#293449 25T OPTION
ALU SERVO HORNS
#293504 23T OPTION
#293505 24T OPTION
#293506 25T OPTION
#293507 23T OPTION
#293508 24T OPTION
#293509 25T OPTION
DETAIL
L=R
INITIAL SETTING
# 352390
GT ALU SHOCK PLATE -
SWISS 7075 T6 (L+R)
# 352390
GT ALU SHOCK PLATE -
SWISS 7075 T6 (L+R)

Xray GTX8 Specifications

General

Width	300mm
Weight	~2080g
Drive Type	4WD
Chassis Material	Aluminum
Terrain	Off-Road
Remote Control Frequency	2.4GHz
Body Material	Polycarbonate
Tire Material	Rubber
Class	Off-road
